The Boeing B-17 ‘Flying Fortress’ was one of the U.S.A.’s main four-engine heavy bombers, operating alongside the B-24 Liberator, and the later B-29 Super fortress, in all theatres of World War 2. It’s a fact that the B-17 almost never saw its place in history and the defeat of Nazi Germany, as the prototype, known as Model 299, crashed due to pilot error during its evaluation in October 1935. Thankfully, the design had shown such promise during the testing phase, in fact exceeding the requirements of the original specification, that further prototypes were ordered despite Boeing losing the original contract with the United States Army Air Corps. It was this further evaluation that saw the type enter active service in 1938. The actual name ‘Flying Fortress’ was coined by a newspaper hack who witnessed a roll-out of the machine, bristling with guns and turrets, and Boeing realised that this was the sort of propaganda they needed, and trademarked the name. After the initial prototypes, serial production of the B-17 began with the B-17B variant, and underwent a major revision with the introduction of the ‘E’. This type featured a substantially redesigned tail and fillet that featured throughout subsequent versions, giving the B-17 its iconic profile. An extra 10ft of length was added to the fuselage. Other refinements included the addition of a tail and dorsal turret, and the addition of a Bendix turret to replace the fixed bathtub type that had graced previous versions. This was found to be disappointing, and was eventually replaced with the Sperry ball turret that became a permanent feature of all future marques.

Download Instruction / Attachment

Instruction (01E029_B-17F_Flying_Fortress__01E029_.pdf, 56,560 Kb) [Download]

Caution

• When you use glue or paint, do not use near an open flame, and use in a well-ventilated room.
• Symbols such as 1.refer to the color number of Mr. COLOR and TAMIYA paints. Glue and paint are not included.
• When you take parts off the runner, use plastic nippers and trim excess plastic with a cutter or a file.
