Features

  • Water-proof and dust-proof, suitable for all weather races.
  • Small size, with built-in capacitor module.
  • Fwd/Rev/Br running mode fits various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse).
  • Great current endurance capability.
  • Great built-in BEC output capacity.
  • Automatic throttle range calibration, easy to use.
  • ESC parameters are easy to set with jumpers.
  • Multiple protections:
  • Over Voltage Protection
  • Low voltage cut-off protection for battery
  • Over-heating protection
  • Throttle signal loss protection.
  • Risk Free manufacturer's limited warranty available through Authorized Dealers in North America

Calibration Video

Specifications
Fwd Cont. Current /Peak Current/ Resistance: 60A/360A/0.001?
Rev Cont. Current /Peak Current/ Resistance: 30A/180A/0.002?
Motor Type Supported: Brushed Motor
Application: 1:10 Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank
Suitable Battery: 2-3S LiPo, 6-9 cell NiMH
Brushed Motor Limit:
2S LiPo or 6 cell NiMH: 540 or 550 Size Motor: ?12T, Or RPM<30000 @7.2V
3S LiPo or 9 cell NiMH: 540 or 550 Size Motor: ?18T, Or RPM< 20000 @7.2V
BEC Output: 2A/5V (Switch Mode)
PWM Frequency: 1KHz
Size/ Weight: 35.5(L)*32.18(W)*18(H) / 39g
Running Modes: Forward/Reverse/Brake, Forward/Brake, Forward/Reverse
Cooling Fan: No need

SKU HW30120201
Barcode # 6938994413084
Brand HobbyWing
Shipping Weight 0.1500kg
Shipping Width 0.110m
Shipping Height 0.080m
Shipping Length 0.160m
Shipping Cubic 0.001408000m3
