Super Soft Start-up

Platinum V4 serial products allows the motor to start extremely smooth and avoids tail-drift
issues that helicopters experience. The start-up time is adjustable from 8 to 25 seconds,
this will definitely create a perfect starting point for every flight.

Excellent Motor Speed Governing

High-performance 32-bit processor with a running frequency of 72MHz combined with
advanced algorithm optimizes the speed governing. Together with the adjustable
governor parameters guarantee every pilot a precise control experience.

Other Features

A separate program port for connecting programmer on this ESC allows user to
● Program ESC,
● Check flight data include minimum voltage, maximum temperature, standardized RPM and speed curve (in Heli Governing Store mode) of the flight parameters recorded by the ESC,
●Upgrade ESC firmware with a mutifunction LCD program box or a WiFi Module & our Apple/Android phone App.

Built-in Sparkproof Circuit

Built-in Arc proof circuit effectively eliminates Arc/Spark produced at
the “powering-on” moment and prolongs the connectors‘ lifespan.

DEO Technology

The DEO (Driving Efficiency Optimization or so-called “Active Freewheeling”) technology implemented in the ESC has multiple advantages.
● Rapider response to throttle change.
● Higher driving efficiency, longer flight time.
● Lower ESC temperature and a more reliable operation.

Four Brake Modes

This Platinum 80A V4 ESC has “Brake Disabled, Normal Brake, Proportional Brake
and Reverse Brake” four brake modes. The brake amount is adjustable in normal
brake mode; in proportional brake mode, the brake force will be automatically
allotted based on the position of radio throttle stick; in reverse brake mode, the
motor rotation can be changed via a spare transmitter channel.

Multiple Protections

Multiple protection features include ESC thermal, capacitor thermal (HOBBYWING-patented technology),
ESC overload, throttle signal loss(or Fail Safe), and low voltage cutoff effectively prolongs the service life of the ESC.



Model Platinum PRO V4 ESC -130A-HV-OPTO
SKU 30209201
Application 550-700 Class Helicopter
Input Voltage 6S-14S Lipo
Cont./Peak Current (10s) 130A/160A
PWM 18KHz
BEC Output No
Separate Programming Port For connecting LCD Program Box/OTA programmer
Input wire Red-12AWG-150mm*1/Black-12AWG-150mm*1
Output wire Black-12AWG-100mm*3
Size 101.0x45.5x27.0mm
Weight 157g / 5.43oz (with cables)

*Note: All the wire length above is the original length not the length you see from the outside.

SKU HW30209201
Barcode # 6938994402675
Brand HobbyWing
Shipping Weight 0.6000kg
Shipping Width 0.100m
Shipping Height 0.080m
Shipping Length 0.200m
Shipping Cubic 0.001600000m3
