Overview

Dualsky ECO 3520C 680kv Brushless Motor

Features

  • Motor structure strength increased by 25%
  • High temperature resistant
  • Water-resistant
  • Rust-proof, high strength main shaft

Specifications

KV   680
Turns   6
Weight   210
Dimensions (D x L)   43.2 x 42.4mm
Ri(mOhm)   24.0
Slots & Poles   12N14P
Io @ 10V (A)   1.3
No. Of Cells (LiPo)
3..5
Max. Efficienct Current [A]   33
Max. Burst Current (15S) [A]   55
Max. Power (15S) [W]   1100
Max. Torque   0.93
Shaft Diameter   6
Mounting Holes Pitch   25/25
Input Connecters   GC4.0
Recommended ESC   XC-65-LITE or XC6018BA
Propeller   4S: 15x10E, 15x8E
5S: 14x5E, 14x7E
Class   50 4-Stroke, .32-.40 (40E) 2-Stroke
SKU DSXM51671
Barcode # 6941047116719
Brand Dualsky
Shipping Weight 0.4000kg
Shipping Width 0.080m
Shipping Height 0.060m
Shipping Length 0.080m
Shipping Cubic 0.000384000m3
