ALIGN TREX H70097A Metal Tail Pitch Assembly
SKU code: H70097A
Make 4 interest-free payments of $13.75 fortnightly and receive your order now.
Suitable for all 700 class machines.
Utilizes dual point attachment design for zero play and higher precision control feel.
Constructed with CNC aluminum alloy, with precision ball bearing at moving points, improving structure rigidity and smoothness, allowing rudder control to be more precise and smooth.
- 6061-T6 Aluminum alloy material and CNC processed.
- I-shaped Arm × 1
- Mount Link × 1
- Mount × 1
- Collar × 1(Φ8×Φ9.4×4mm)
- Bearing holder × 1
- Bearing MR128ZZ × 2(Φ8xΦ12x3.5mm)
- Linkage ball C(M3x3.5) × 1(Φ5x8.5mm)
- Tail control arm × 1(38.7×10.7×4mm)
- Bearing F682XZZ × 6(Φ2.5×Φ7.1Φ2.6mm)
- Socket button head screw × 1(M3x5mm)
- Socket button head screw × 6(M2.5x5mm)
- Socket button head screw × 1(M2.5x6mm)
SKU | H70097A |
Barcode # | 4713414000189 |
Brand | Align |
Shipping Weight | 0.5000kg |
Shipping Width | 0.080m |
Shipping Height | 0.080m |
Shipping Length | 0.080m |
Shipping Cubic | 0.000512000m3 |
